Blushless 60w 2500rpm Dustproof Ac Ventilation Fan 110v / 120v Large Air Flow
Large air flow 110V / 120V blushless fan 60w 2500rpm ac dustproof ventilation fan
Specification
MX20060ABH11
| Basic specification | Beaing type | Ball bearing |
| Rated voltage | 110V / 120V |
| Input power | 60W |
| Speed | 2500RPM/2800RPM |
| Max air flow | 420/490CFM |
| Function | Waterproof /dustproof |
| | | |
| Meteial and structure | Frame | 94V-0 fireproof |
| Impeller | 94V-0 fireproof |
| Motor | Reverse Polarity Protected |
| Leadwire | 2 wires(red+,balck-) |
| Connector | |
| | | |
| Performance | Expected life | |
| Ball bearing | 50000 hours(40℃) |
| Sleeve bearing | 30000 hours(40℃) |
| Allowwable temperature range | |
| operating | –10℃ to +60℃ |
| storage | –40℃ to +70℃ |
General specifications
Frame and Impeller: 94V-0 fireproof, metal frame and plastic impeller
Bearing Type: Ball bearing
Function Range: IP55,IP58,IP66,IP68, Waterproof and dustproof
Leadwire: Red Wire Positive(+),Black Wire Negative(-)
Operating Voltage: AC110V 120V 220V 240V
Tempetature Range: –10℃ to +60℃
Motor: Impedance Protected and Reverse Polarity Protected
Expected life: <80000 hours
FEACTURE :function/speed/voltage Manufacture according to your demands!
Dustproof ventilation fan: 110v/120v
Product testing
Our Market
We have an experienced and professional team of manufacturing fan. Our product exported to many countries. Our main markets are south Asia,south America, Europe.
“Concentrate on the sevice of customer” is our purpose. We welcome customers, bussiness associations and friends from all part of world.
We hope to meet your cooperation sincerely.
Our company
Founded in 1996 in Shenzhen China, we, Shenzhen Topfan-China Technology Co., Ltd, is professional manufacturer and researcher on dc brushless fans and ac fans. Our products are ISO9000, CE, RoHS and TUV certificated and good sellers both at home and abroad, including European, North American, Asia(Korea and India) and so on. The products, including brushless fans, cross flow fans, blower fans, centrifugal fans, dc brushless motor, shades pole and RC ac fans, are being widely used in the information technology, network communications as well as industrial production equipment, medical equipment, home appliances and others. Based on mutual benefit and development, we always make our biggest efforts to do everything better for our customers.
Packing:
Carton box or according to customers demand
Shipment:
1. FOB Shenzhen or HongKong (mass production)
2. DHL,UPS,FEDEX,TNT or any other international express (sample or small quantity)
Delivery Time:
Generally, 500~1000pics 10 days after confirming the PI
